2017 Year

Diesel Fuel

Loading capacity Ton: 7,500 kgs 4,600 kgs

Finance: Available

ENGINE
Model TATA 697 TC/IC
Type Water-cooled, Direct injection Turbocharged Intercooled diesel engine
Displacement 5675 cc
No. of Cylinders 6 In-line
Bore / Stroke 97 mm x 128 mm
Max. Power Output 129 PS @ 2,400 rpm
Max. Torque Output 42 kg-m @ 1,400 rpm – 1,700 rpm
Compression Ratio 18.5:1
PERFORMANCE
Max. Speed (km/hr) 112 kph
Max. Gradeability 36 %
Turning Radius (m) 6.8
CLUTCH
Type Dry single plate friction type, Booster assisted
Outside Dia. of Clutch 310 mm
TRANSMISSION
Model and Type TATA GBS-40, 5-speed, overdrive, Synchromesh on all forward gears
No. of Gears 5 Forward, 1 Reverse
Gear Ratios 1st – 6.34, 2nd – 3.37, 3rd - 2.11, 4th - 1.28, 5th - 1, Rev – 5.85
REAR AXLE
Type Single Banjo, Fully-floating type, Hyphoid Gear
Final Gear Ratio 3.111 (28 /9 )
BRAKES
Type Drum, Dual Circuit Full Air S-CAM Brake
Auxiliary Brake Exhaust Brake, coupled w/ Service Brake
Parking/Maxi Brake Spring Actuated acting on rear wheels

WEIGHTS
GVW 7,500 kgs
Payload 4,600 kgs
MAIN CHASSIS DIMENSIONS
Wheel Base 3,800 mm
Front Track 1,650 mm
Rear Track 1,577 mm
Overall length 7,125 mm
Over All Width 2,140 mm
SUSPENSION
Front Semi-elliptical leaf spring w/ hydraulic double acting telescopic type shock absorber
Rear Semi-elliptical leaf spring w/ hydraulic double acting telescopic type shock Absorber & Auxiliary Springs
WHEELS AND TIRES
Tyres 7.5R16-14PR Radial Ply
Wheels and Rims 6 G x 16 SDC
No. of Wheels Front -2, Rear –4, Spare -1
CHASSIS FRAME
Type Ladder type frame with riveted /bolted cross members. Side members are of channel section Depth : 200 mm, Width : 60 mm, Thickness : 5 mm
ELECTRICAL SYSTEN
Battery 1-12 Volts (180Ah capacity)
Alternator Capacity 65 Amps
FUEL TANK (Round)
Capacity 120 litres
