2017 Year

Diesel Fuel

Loading capacity Ton: 16,200 kgs 10,700 kgs

Finance: Available

Model CUMMINS B235 20
Type Water-cooled, Direct injection Turbocharged Intercooled diesel engine
Displacement 5883 cc
No. of Cylinders 6 In-line
Bore / Stroke 102 mm x 120 mm
Max. Power Output 230 PS @ 2,500 rpm
Max. Torque Output 82.9 kg-m @ 1,500 rpm
Compression Ratio 17.3:1

Max. Speed (km/hr) 105 kph
Max. Gradeability 35 %
Turning Radius (m) 10.4

Type Dry single plate friction type
Outside Dia. of Clutch 380 mm

Model and Type EATON FSO 8406A, 6-speed, overdrive, Synchromesh on all forward gears
No. of Gears 6 Forward, 1 Reverse
Gear Ratios 1st - 7.05, 2nd - 4.13, 3rd - 2.52, 4th - 1.59, 5th - 1, 6th – 0.78, Rev – 6.75

Type Single Banjo, Fully-floating type, Hyphoid Gear
Final Gear Ratio 5.857 (41 /7 )
BRAKES
Type Drum, Fully Duplicated Full Air S-CAM Brake System with ABS
Auxiliary Brake Exhaust Brake, operation through brake pedal
Parking/Maxi Brake Spring Actuated acting on rear wheels


WEIGHTS
GVW 16,200 kgs
Payload 10,700 kgs
MAIN CHASSIS DIMENSIONS
Wheel Base 5,195 mm
Front Track 1,955 mm
Rear Track 1,860 mm
Overall length 9.170 mm
Over All Width 2,492 mm
SUSPENSION
Front Semi-elliptical leaf spring w/ hydraulic double acting telescopic shock absorber and Anti roll bar
Rear Semi-elliptical leaf spring w/ hydraulic double acting telescopic shock absorber
WHEELS AND TIRES
Tyres 11R22.5-16PR
Wheels and Rims 8.25 x 22.5
No. of Wheels Front -2, Rear –4, Spare -1
CHASSIS FRAME
Type Ladder type heavy duty frame, Depth: 285 mm (Max) Width: 888 mm, Thickness: 7mm
ELECTRICAL SYSTEN
Battery 2-12 Volts (150Ah capacity)
Alternator Capacity 75 Amps
FUEL TANK (Round)
Capacity 350 litres
